Type | 20/30/60/80/100 |
|
|
|
Power | 20W/30W/60W/80W/100W |
|
|
|
Laser Wavelength | 1064nm |
|
|
|
Marking Area | 150mm*150mm |
|
|
|
Optional Marking Area | 100mm*100mm / 150mm*150mm/200mm*200mm / 300mm*300mm |
|
|
|
Marking Depth | ≤1.2mm |
|
|
|
Marking Speed | 800 standard characters/second |
|
|
|
Minimum Line Width | 0.012mm |
|
|
|
Minimum Character | 0.15mm |
|
|
|
Repeated Precision | ±0.003mm |
|
|
|
Life-span of Fiber Laser Module | 100 000hours |
|
|
|
Beam Quality | M2 <1.5 |
|
|
|
Focus Spot Diameter | <0.01mm |
|
|
|
Output Power of Laser | 10%~100% continuously to be adjusted |
|
|
|
System Operation Environment | Windows XP / W7--32/64bits / W8--32/64bits |
|
|
|
Cooling Mode | Air cooling--Built-in |
|
|
|
Temperature of Operation Environment | 15℃~35℃ |
|
|
|
Power Input | 220V / 50HZ / single phase or 110V / 60HZ / single phase |
|
|
|
Power Requirement | <400W |
|
|
|
Communication Interface | USB |
|
|
|
Machine Dimension/after package | 650mm*210mm*550mm/880*420*700mm |
|
|
|
Net Weight/gross weight | 30KG/53kgs |
|
|
|
Optional (Not free of charge) | Rotary Device, Moving Table, other customized Automation |
|
|
|
